Product Description
Description;
Double Pole MCB for Primary input overload protection.
Heavy duty sheet steel enclosure to IP44.
Output sockets to BSEN 60309 / IEC 60309 (Previously BS4343).
Each 32A & 16A 110V socket outlet individually MCB protected.
Each 16A 110V lighting circuit MCB protected as standard (can be supplied c/w MCB/RCD protection as optional extra)
Specifications;
Weight (kg): 70
Height (mm): 550
Depth (mm): 440
Width (mm): 430
Protection: Input – 1 x 50A 2P Schneider MCB,
Outputs – 6 x 16A 2P Schneider MCBs & 2 x 32A 2P Schneider MCB’s.
Continuous Rating: 10kVA
Input Voltage: 1 Phase 230V
Output Voltages: 110V CTE
Output Sockets: 4 No. 16A + 2 No.32A 110V
IP Rating: IP44
Terminals: Internal Din rail mounted terminals for 2.5 – 16.0mm²
